Teaching Physics #5 - Properties Of Liquids Through Simple Experiments

Hello steemit educators, parents and anyone else interested in physics or...trolls! In this series I present you with simple and safe experiments you can try out with very basic and cheap materials. For this reason they are perfect for teachers in primary school and parents who want to show their children that science lies hidden everywhere and awaits to be discovered...

The first three posts of this series were on the properties of air (you can find them here, here and here). The fourth post was on liquids and more specifically, hydrostatic pressure. This one is about buoyancy.

OBJECTIVES

Teach what buoyancy is and what factors it depends on (density of fluid and volume of the submerged object).

DETECTING FORMER KNOWLEDGE

We all have seen how objects float or submerge in liquids (and even though Pennywise whispers in my ears that "They all float down there" I don't believe him). First we should have our children think what would make an object float or submerge within a liquid mass. We can ask questions like:

- How can both a plastic ball and a huge cruise-ship float at sea?
- Why is it easier to float at sea than in a swimming pool?

After the students' curiosity has been "activated" we can go on presenting our theory:

Buoyancy is a force that "works" opposite gravity, by pushing an object upwards when its weight pushes it downwards. In even simpler words, buoyancy is an object's ability to float in a liquid. When buoyancy equals the weight of the submerged object, then it floats. The force of buoyancy depends on several factors, including the specific gravity of the liquid, the volume of the object (that is equal to the displaced volume of the liquid).

 Math formula: Fb = p × g × V
Fb = the force of buoyancy (N), p = the liquid's density  (kg/m3) , g = acceleration of gravity  (9.80 m/s2), V = the displaced volume of the liquid  (m3 or liters)

(Image source: wikipedia.org)

EXPERIMENT 1

Buoyancy is related with the specific gravity of the fluid (the ratio of the liquid's density to the density of a reference liquid, usually water).

SG = ρ sample/ ρ reference, where ρ = density

Materials:

• a glass
• an egg
• water
• salt

Process:

1. Pour some water in the glass.
2. Dip the egg inside.
3. Then, remove the egg and put two-three tablespoons of salt.
4. Dip the egg again.



In the first case the egg gets to the bottom. After adding salt to the water, the egg floats.

Conclusion: Water has different special gravity than salt water, so buoyancy increases and the egg floats. That's why swimming in a pool can be harder than swimming in the sea.

EXPERIMENT 2

Children tend to believe that heavy objects will submerge, but how can they explain the fact that ships float? Buoyancy depends on the volume of the object. A great example for kids to understand that is the experiment below:

Materials:

• a big glass
• a smaller plastic glass
• some small objects like nails, pins or marbles

Process:

1. Pour some water in the big glass.
2. Place some of the marbles inside the smaller glass.
3. Put the smaller glass in the big one.
4. Then, remove the smaller glass.
5. Put all the objects in the big glass and place the smaller glass in the big one again.



At first there is a balance and the heavy plastic bottle floats. When we take the objects out of the plastic glass and put them directly to the big one, they don't float. Check also how much has the water level risen.

Conclusion: In the second case, buoyancy is not great enough to push the balls to the surface, their weight hasn't changed from the first try, but their volume has.

Note: I know I don't cover the matter completely, this is just a simple demonstration of two easy experiments, ideal for primary school students. You might have noticed that I don't go into further details and math formulas. That is because the aim of those experiments is to make children curious about the results of their observations. For younger children too complex math types are not suitable, we just want to make a simple introduction to the concept. Of course, for older children those experiments can and should be accompanied with more thorough explanations including math formulas, problems and even more complex experiments.

References

wikipedia.org_1
wikipedia.org_2
softschools.com

Panagiotis Koumaras, "A guide to teaching physics through experiments" - Christodoulidis Editions (Thessaloniki 2005)

*All non-credited images by @ruth-girl

Thank you for being here and reading my post, perhaps some of you will find it interesting and give those experiments a try. If you do so, please leave a comment on how they worked for you and your class. You may also want to suggest any other experiments or projects to make this lesson even better. It would make me even happier if you were a parent and tried those simple experiments with your child/children, they are so simple, you can easily do them at home.
